- מותג: Hertz
- דגם: HCP 4DK
- גליון נתונים טכני: לחץ להורדה
- מדריך למשתמש: לחץ להורדה
The new HCP 4DK features latest generation D-Class 2Ω stable output stage reaching the impressive max power of 2000 W with the excellent S/N ratio of 105 dB. Extremely versatile, complete in its functions, provided with Speaker-In and RCA-In inputs to work with any head units, it has been designed to work also in mono (selectable mode), for a three-channel system with sub and front, or a powerful two-channels system. All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.
Technologies
-
LATEST GENERATION D-CLASS
The new HCP 4DK features latest generation D-Class 2Ω stable output stage reaching the impressive max power of 2000 W with the excellent S/N ratio of 105 dB.
-
REFINED HEATSINK WITH HIGH CONVECTION CAPABILITY
The extruded aluminum heatsink provides high efficiency thermal performance; using the top side of the heatsink to effectively dissipate the heat generated by the electronic components. The internal temperature remains constant at all power levels.
-
COMPLETED FILTER SECTION
Large array of filters customized for each model, to achieve maximum versatility: Lo-Pass, Hi-Pass, Band-Pass, Full Range, Bass Boost, Phase and Mono.
-
ART
Automatic Remote Turn-On/Off function, automatically turns the amplifier on and off with the OEM radio; eliminates the need for a remote signal from the source when using the Speaker-In. This function can also be disabled.
- Channel mode 4 – 3 – 2
- Output Power (RMS)
@ 14.4 VDC 4 Ch: 150 W x 4 (4 Ω)
4 Ch: 250 W x 1 (2 Ω)
3 Ch: 150 W x 2 (4 Ω) + 520 W x 1 (4 Ω)
3 Ch: 250 W x 2 (2 Ω) + 520 W x 1 (4 Ω)
2 Ch: 520 W x 2 (4 Ω) - Filters
Bypass Yes
Hi-Pass A/B: 50 ÷ 3.2k Hz @ 12 dB/Oct.
Lo-Pass A/B: 50 ÷ 3.2k Hz @ 12 dB/Oct.
Band-Pass –
Subsonic No - Distortion – THD (100Hz @ 4Ω) 0.03%
- S/N Ratio (A weighted @ 1V) 105 dB
- Damping factor (100Hz @ 4Ω) 200
- Size W x D x H mm (in.) 315 x 190 x 50 (12.40 x 7.48 x 1.97)
